SPC UV Coating Line
Applications
UV Coating line is a brand-new product designed by our company for
LVT SPC WPC Flooring.It is energy-saving,efficient and stable.The
roller coater is divided into three sections.The whole machine has
3sets of motor groups independently controlled,convenient operation
and maintenance,high safety factor and good effect during the
coating process.UV dryer can be equipped with electronic variable
control system/UV-LED cold light source,power dryer,paint film dry
effect is more perfect.
Quick Detail
This production line consists of 8 machines.
1. The first electrostatic precipitator is used to remove static
electricity on the surface of SPC.
2. The second hot air dryer is used to soften the board surface.
3. The third single roll coater is used to paint the board surface.
4. The fourth double-lamp UV dryer is used for semi-dry paint.
5. The fifth single-roll coater is used to apply paint to the
floor.
6. The sixth leveling machine are used to eliminate air bubbles and
control gloss.
7. The seventh six-lamp dryer is used to completely dry the paint.
8. The eigth conveyor is used to inspect the floor and receive
floor.
Specifications
Competitive Advantage
We are the best coating manufacturer in China, with a market share
of 60% in China. The products are sold to the United States,
Brazil, Africa, the Netherlands, South Korea, and India ... Our
equipment configuration is very high, and the dryer uses electronic
power supply. 25% energy saving, higher energy intensity and faster
production speed. The roller coater is very precise, and the
surface effect of the product is very good, without horizontal
stripes. We have a strong after-sales team, no matter where you are
on the earth, we can provide the best service.
Technical parameters
| model | JZ-1300# |
| Number of machines | 9 |
| Colour mode | white |
| Working width | 1300mm |
| Painting speed | 15-25 meters per minute |
| Heating and drying system | UV lamp |
| Power on | 170KW |
Company profile
JINGZHI Machinery Manufacturing Co., Ltd. is located in Huaqiao
Industrial Park, Suzhou City. We are an enterprise combining the
research, design, development, manufacturing, sales and technical
services of painting and printing machinery.
1. Our machinery is widely used in printing and coating the plastic
floor, solid wood, composite floor, wallboard, plywood, door board,
foaming board, medium and high-density board, calcium silicate
board, wood, modular furniture, etc. Our machine applies to
UV.PU.NC. Waterborne paint.
2. The machine type: Precision roller coating machine, Precision
color brush machine, Putty filling machine, Curtain machine, UV
dryer, LED dryer, Hot air dryer, Vacuum spraying machine, Sanding
machine, Polishing machine, Jet air dryer.
3. Our company made a number of product patents, some of which had
filled a number of gaps in technology in China.
4. Our foreign customers: Iran, Brazil, Japan, USA, Netherlands,
Vietnam, Malaysia, Indonesia, Ethiopia, etc.
In accordance with customers' actual production needs, our company
provides the most scientific and rigorous production process and
equipment for every customer. Our products not only achieve the
best effect of painting but also thoroughly solve many production
problems, such as environmental pollution, low efficiency & high
cost, which are caused by the traditional painting process.
